Junior 80/B Sliding Door Hardware System with 25/31 Inch M10 Bolt
Rating 4.5 | 2 Reviews | Our Item Number HAF-940.80.004
$
755.65
$944.56
SAVE 20%
Ends Nov 03
Ends Nov 03
Product Info Length: 8-11/16 Inch, Width: 5-1/2 Inch, Height: 1-9/16 Inch, Model series: Junior 80/B, Weight: 2.2 lb, See more product details
Large Project?
Orders $2500+ Qualify for Special Discounts.
Build your item list and get a Quick Quote
view bid cartAll the product info you could ask for...
-
Size Info
- Length : 8-11/16 Inch
- Width : 5-1/2 Inch
- Height : 1-9/16 Inch
- Adjustment Height : +/- 4 mm (track buffer with adjustable retaining spring and cover cap)
- Key Features : Suitable for a single sliding door without upper track and lower guide
For 1 and 2 sliding wood doors
Low wear and tear
Quiet running action
Optional soft and self closing mechanism (Hawa-SoftMove 80 only)
For door thickness: Min. (1 3/16") 30 mm
For low headroom applications, gap between the door and upper track can be as small as 1 mm (1/32")
Set with 20 mm (25/32") longer suspension bolt available which allows up to 22 mm (7/8") thick ceiling tiles to overlap the upper track
Height adjustable: +/- 7 mm (9/32")
Coarse adjustment +/- 3 mm (1/8")
Fine adjustment +/- 4 mm (5/32")
Track stopper with adjustable retention spring
Order 2 sets for 2-leaf sliding doors
-
Manufacturer Info
- Manufacturer : Hafele
- Manufacturer Part # : 940.80.004
-
Other Important Info
- Door Weight : (176 lbs) 80 kg
- Model series : Junior 80/B
- Installation : Suspension with recessed support profile and installation-friendly suspension carriage with integrated metal cover cap; suspension of running gears from below using hanger bolt; wall mounting and ceiling installation
- Weight : 2.2 lb
- Product Type : Sliding Door Hardware
- Includes : 2 running gears, 2 support profiles with suspension carriage and M10 hanger bolt, 2 track buffers with retaining spring, 1 wall buffer, 1 floor guide
