U-Shaped Under Sink Soft-Close Pull-Out for 36" Width Sink Bases, Bottom-Mounted, Chrome Wire Frame, Gray Bottom, Min. Opening: 32-11/16" Width x 21-3/4" Depth x 7" Height
Rating 4.6 | 419 Reviews | Our Item Number RV-5386-33BCSC-GR
Rev-A-Shelf's 5386 Pullout U-Shaped Series feature beautiful maple or contemporary solid bottoms. Designed for 33 and 36 sink base cabinets, the unique u-shaped frame fits around even the peskiest pipes. Units glide on Blum full-extension, soft-close slides, can be side or bottom mounted and can also be individually door mounted with included brackets.
$
456.35
$612.99
SAVE 26%
Ends Jun 30
Ends Jun 30
Free Shipping on Rev-A-Shelf - Orders $99+
Use Code REVASHELF2606 Expires 6/30/2026
Use Code REVASHELF2606 Expires 6/30/2026
Color: Gray
Product Dimensions:
Need Help? Contact Us Now
Product Info Width: 32.5 Inch, Depth: 22 Inch, Height: 5.25 Inch, Slides: Yes, Soft Close: Yes, See more product details
Large Project?
Orders $2500+ Qualify for Special Discounts.
Build your item list and get a Quick Quote
view bid cartAll the product info you could ask for...
-
Size Info
- Minimum Opening for a Face Frame Cabinet : 32-11/16" Width x 21-3/4" Depth x 7" Height
- Width : 32.5 Inch
- Depth : 22 Inch
- Height : 5.25 Inch
- Full Product Dimensions (Millimeters) : 825.5 mm W x 558.8 mm D x 133.35 mm H
- Slide Type : 75lb Full-Extension Blummotion slide system
- Feature 3 : Will adjust from 32.5" to 34.75" Width
-
Manufacturer Info
- Manufacturer : Rev-A-Shelf
- Manufacturer Part # : 5386-33BCSC-GR
-
Other Important Info
- Slides : Yes
- Soft Close : Yes
- Category Groupings : U-Shaped Sink Organizer w/Blum SC
- Sub-Class : Sink Base Cabinet
- Ship Type : Small Parcel
- Product Type : Base Cabinet Organizers
- Keywords : Kitchen, Cabinet Organization, under sink
- All Features : Included: (1) U-Shape Gray Basket, Slides, Door mount kit, Hardware
Slide Type: 90lb Full-Extension BLUMOTION Slides w/Soft-Close
Bottom or side mounting for total stability
Purchase multiple baskets to create a fully accessible cabinet
U-Shaped design works around most plumbing and other obstructions in sink base cabinets
Designed for a 33" Opening
Door mount brackets: Adjustable door mount brackets are included and required for operation
Construction: Heavy-Duty Metal frame with solid bottom surface
Can mount to the floor or side of cabinet
Limited Lifetime Warranty - Actual Product Width (Inches) : 32.5
- Actual Product Depth (Inches) : 22
- Weight : 16.5 lbs
- Actual Product Height (Inches) : 5.25
- Full Product Dimensions : 32.5"W x 22"D x 5.25"H
- Actual Product Weight (lbs) : 16.5
- Product Series : SB9 - 5322 Series
- Minimum Cabinet Frameless Opening (Inches) : 33.25
- Color : Gray
- Actual Product Width (Millimeters) : 825.5
- Material : Steel
- Actual Product Depth (Millimeters) : 558.8
- Country of Origin : Italy
- Actual Product Height (Millimeters) : 133.35
- Contains Wood : Yes
- Material Breakdown : Medium Density Fiber (MDF); Steel
- Actual Product Weight (Kilograms) : 7.425
- Material Breakdown % : 30;70
- Minimum Cabinet Faceframe Opening (Millimeters) : 825.5
- Wood Type : MDF
- Minimum Cabinet Frameless Opening (Millimeter) : 844.55
- Includes : (1) U-Shape Gray Basket, Slides, Door mount kit, Hardware
- Primary Color : Gray
- Number of Tiers : 1
- Feature 1 : Bottom or side mounting for total stability
- Number of Shelves : 1
- Feature 2 : U-Shaped design works around most plumbing and other obstructions in sink base cabinets
- Gas Assist : No
- Material Bre : Medium Density Fiber (MDF); Steel
- Fits or Designed for : Designed for a 33" Opening
- Included optional Door Mount / Door Extender : Door mount brackets included
- Construction / Finish : Heavy gage wire construction with solid bottom shelves
- Installation : Can mount to the floor or side of cabinet
- Warranty : Limited Lifetime Warranty
Manufacturer Resources
-
